Ortofon Concorde Music Red

Ortofon Concorde Music Red - High-quality hi-fi cartridge for passionate music lovers

The Ortofon Concorde Music Red is more than just a cartridge - it is a statement for all those who not only want to listen to music, but also experience it. As part of the exclusive Concorde Music series, this model stands for precision, expressiveness and design. Developed by music lovers for music lovers, the Concorde Music Red transforms every record into a captivating, emotional sound journey - without any technical hurdles.

With its elegant look in black and red, its tool-free assembly and its excellent sound quality, this cartridge is aimed at both experienced hi-fi enthusiasts and discerning beginners. The combination of technical finesse and aesthetic appeal makes it a real highlight in any setup.

Ortofon - A brand with a passion for analog sound

Ortofon has been synonymous with high-quality cartridges and first-class audio design for over 100 years. Based in Denmark, the company develops products that impress through innovation, quality and musical passion. The Concorde Music series is an expression of this tradition and sets new standards in hi-fi listening pleasure.

The Concorde Music Red is the perfect entry-level model into this new world of sound. It impresses with its versatility, easy handling and a lively, dynamic sound - ideal for all types of music and any record collection.

Technical details of the Ortofon Concorde Music Red

With an output voltage of 6 mV, the Concorde Music Red delivers a powerful, clear signal - ideal for phono preamps and integrated phono inputs. The channel balance at 1 kHz is 1.5 dB, which enables a clean, centered stereo image.

The channel separation is 22 dB at 1 kHz and 15 dB at 15 kHz - a value that ensures clear spatial imaging. The frequency response covers the entire audible range from 20 Hz to 20 kHz, with a tolerance of +3 / -1 dB, which speaks for a balanced and natural sound reproduction.

A particular highlight is the scanning capability of 80 µm at 315 Hz and recommended tracking force - a value that ensures precise tracking and minimal distortion even in complex passages. The dynamic lateral compliance is 15 µm/mN - a good average value that optimally combines sound quality and record protection.

The stylus diamond is an elliptically cut diamond that sits on an aluminum stylus carrier. This design - with a stylus tip radius of r/R 8/18 µm - offers excellent groove tracking and also reveals fine details in the music.

The recommended tracking force is 1.8 g, the tracking angle is 20°, both ideally matched to a wide range of tonearms. With a cartridge weight of 18 g, the Concorde Music Red fits all common systems with SME connection without any problems - and without any tools.

The recommended load resistance is 47 kΩ, the recommended load capacitance is 150-300 pF - both standard values for high-quality hi-fi components. This makes the cartridge maximally compatible and delivers a consistently strong performance in a wide variety of setups.

Why the Ortofon Concorde Music Red is the ideal choice for vinyl enthusiasts

With the Concorde Music Red, you get a cartridge that combines hi-fi performance, ease of use and design. The tool-free assembly makes it very easy to get started - even for beginners. No adjustment, no screws, no soldering: just plug it in and get started.

Its elliptical diamond in combination with an aluminum carrier ensures excellent scanning of the record groove - regardless of whether it is a new release or a vintage LP. It offers a sound characteristic that is warm, detailed and powerful at the same time - ideal for all music genres, from jazz and pop to classical or electronica.

The Concorde Music Red is a real all-round talent for discerning music lovers who want to get started with the Concorde Music series without compromising on sound quality. Whether for everyday listening or special sessions - this cartridge transforms your records into vibrant soundscapes.

Features:

• Part of the new Concorde Music series from Ortofon
• Elliptical diamond on aluminum stylus
• Stylus tip radius: r/R 8/18 µm
• Output voltage: 6 mV at 1 kHz, 5 cm/sec
• Channel balance at 1 kHz: 1.5 dB
• Channel separation: 22 dB (1 kHz), 15 dB (15 kHz)
• Frequency response: 20 Hz - 20 kHz (+3 / -1 dB)
• Sampling capability at 315 Hz: 80 µm
• Compliance (dynamic, lateral): 15 µm/mN
• Recommended tracking force: 1.8 g
• Sampling angle: 20°
• Pickup weight: 18 g
• Color: Black/Red
• Recommended load resistance: 47 kΩ
• Recommended load capacity: 150-300 pF
• Tool-free installation for quick and easy mounting
• Ideal for music lovers who want to combine sound quality and comfort
